Tekniske detaljer Deviate Highlander 140

Spec Deviate Highlander 140

Rear Wheel: 29”, Boost: 148mm * 12mm

Fork Compatibility: 29” 150-160mm with 44/42mm offset

Bottom Bracket: 73mm BSA Threaded

Headset: ZS44/28.6 upper and a ZS56/40 lower headset cup

Cranks: Minimum Q-factor of 168mm

Chainline: 52mm

Chain length: 126 links (widely available, no need to join chains)

Max Chainring Size: 36t

Shock Size: Metric 210*55mm

Shock Hardware: Front: 30*8mm | Rear: bushing

Brake Mount: Post Mount 180mm

Seatpost Compatibility: Internal dropper routing with internal cable routing. 31.6”, Max Insertion Depth: Medium:- 300mm, Large:- 330mm (that's a 200mm Reverb at full insertion even on the M)

Seat Collar: 34.9mm

Chain: 126 link chain - commonly available with no need to join chains.

Tyre clearance: 2.8”
